BS7835 3 Core Armoured Power Cable 33kV - XLPE, PET, SWA, LSZH - 95mm to 185mm
OVERVIEW
Overview
The 33KV triple core power cable, is just a small part of our medium voltage cable range, it is suitable for power networks, underground, outdoors and installation in cable ducting.Please note: the red outer sheath can be prone to fading when exposed to UV rays.
The 33KV triple core power cable, is just a small part of our medium voltage cable range, it is suitable for power networks, underground, outdoors and installation in cable ducting.Please note: the red outer sheath can be prone to fading when exposed to UV rays.
Standards
- BS 7835
- BS EN/IEC 60754-1
- BS EN/IEC 60228
- BS EN/IEC 60332-1-2
CONSTRUCTION
Conductor: Stranded Plain Annealed Circular Compacted Copper Conductors
Conductor Screen: Semi-conductive XLPE
Insulation: Cross-Linked Polyethylene (XLPE)
Insulation Screen: Semi-conductive XLPE
Metallic Screen: Individual or collective overall copper tape screen
Filler: Polyethylene Terephthalate fibers (PET)
Separator: Binding tape
Bedding: Low Smoke Zero Halogen (LSZH)
Armour: SWA (Steel Wire Armoured)
Sheath: Low Smoke Zero Halogen (LSZH)
CHARACTERISTICS
Voltage Rating: 33000 Volts
Temperature Limits: -15°C to +90°C
Minimum Bending Radius: As per cable manufacturer datasheet
Should not be installed at temperatures below 0°C or above +40°C
