218*Y Flexible Cable - H03VV-F, PVC - 0.5mm to 0.75mm
OVERVIEW
Overview
PVC Flex cable is used as an electrical supply to many household appliances such as refrigerators, washing machines and spin dryers. Plain annealed flexible copper conductors, PVC insulated, PVC outer sheath. Not advised for outdoor use. Available in 100M reels.
PVC Flex cable is used as an electrical supply to many household appliances such as refrigerators, washing machines and spin dryers. Plain annealed flexible copper conductors, PVC insulated, PVC outer sheath. Not advised for outdoor use. Available in 100M reels.
Standards
- BS EN 50265-2-11
- 218*Y H03VV-F
Construction
Conductor: Plain annealed flexible stranded copper conductor
Insulation: Polyvinyl Chloride (PVC)
Sheath: Polyvinyl Chloride (PVC)
WH – Denotes white Sheath, not Black
Characteristics
Voltage Rating: 300 Volts
Temperature Limits: Fixed: -5°C to + 60°C | Flexing +5°C to +60°C
Minimum Bending Radius: As Per Manufacturers Datasheet
Should not be installed at temperatures below 0°C
