6381Y Flexible Cable - Single Core, BS 6004, PVC - 6mm to 400mm
6381Y Flexible Cable - Single Core, BS 6004, PVC - 6mm to 400mm



OVERVIEW

Overview
Flexible, single core, PVC telecoms cable. For use in DC power supplies on telecomms equipment and power applications where flexible cable is a requirement.
STANDARDS
  • 1.5mm2 to 35mm2: Generally to BS 6004
  • 50mm2 and above: BS EN/IEC 60502-1
  • BS EN/IEC 60332-1-2
CONSTRUCTION

Conductor: Flexible Copper Conductor
Insulation: Poly Vinyl Chloride (PVC)
Sheath: Poly Vinyl Chloride (PVC)

CHARACTERISTICS

Voltage Rating:
1.5mm2 to 35mm2: 450/750V
50mm2 and above: 600/1000V
Temperature Limits: -15°C to +70°C
Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed at temperatures below 0°C or above +60°C

PRODUCTS

CodeDescription
6381Y61X6.0 FLEX,PCW,PVC,PVC,BLUE,BLUE GEN TO BS6004
6381Y61X6.0 FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS6004
6381Y61X6.0 FLEX,PCW,PVC,PVC,WHI,WHI GEN TO BS6004
6381Y101X10 FLEX ,PCW,PVC,PVC,BLUE,BLUE GEN TO BS6004
6381Y101X10 FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS6004
6381Y101X10 FLEX ,PCW,PVC,PVC,WHITE,WHITE GEN TO BS6004
6381Y161X16FLEX,PCW,PVC,PVC BLUE,BLUE GEN TO BS6004
6381Y161X16FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS6004
6381Y161X16 FLEX,PCW,PVC,PVC,GREEN/YELLOW,GREEN/YELLOW GEN TO BS6004
6381Y161X16FLEX,PCW,PVC,PVC,WHI,WHI GEN TO BS6004
6381Y251X25FLEX,PCW,PVC,PVC,BLUE,BLUE GEN TO BS6004
6381Y251X25FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS6004
6381Y251X25FLEX,PCW,PVC,PVC,WHI, WHI GEN TO BS6004
6381Y251X25FLEX,PCW,PVC,PVC,RED, RED GEN TO BS6004
6381Y351X35FLEX,PCW,PVC,PVC,BLUE,BLUE GEN TO BS6004
6381Y351X35FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS6004
6381Y351X35FLEX,PCW,PVC,PVC,WHI, WHI GEN TO BS6004
6381Y501X50 FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y501X50 FLEX PCW,PVC,PVC,BLUE,BLUE GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y501X50 FLEX PCW,PVC,PVC,WHITE,WHITE GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y701X70 FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y701X70 FLEX,PCW,PVC,PVC,BLUE,BLUE GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y701X70 FLEX,PCW,PVC,PVC,WHITE/WHITE GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y951X95 FLEX,PCW,PVC,PVC,BLUE,BLUE GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y951X95 FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y1201X120 FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y1201X120 FLEX,PCW,PVC,PVC,BLUE,BLUE GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y1501X150 FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y1501X150 FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y1851X185 FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y1851X185 FLEX,PCW,PVC,PVC,GREY,GREY GEN TO BS-EN 50525-11 AND IEC60502 600/1000V
6381Y2401X240 FLEX,PCW,PVC,PVC,BLUE,BLUE BS-EN 50525-11 AND IEC60502 600/1000V
6381Y2401X240 FLEX,PCW,PVC,PVC,GREY,GREY BS-EN 50525-11 AND IEC60502 600/1000V
6381Y3001X300 FLEX,PCW,PVC,PVC,BLUE,BLUE BS-EN 50525-11 AND IEC60502 600/1000V
6381Y3001X300 FLEX,PCW,PVC,PVC,GREY,GREY BS-EN 50525-11 AND IEC60502 600/1000V
6381Y4001X400 FLEX,PCW,PVC,PVC,BLUE,BLUE BS-EN 50525-11 AND IEC60502 600/1000V
6381Y4001X400 FLEX,PCW,PVC,PVC,GREY,GREY BS-EN 50525-11 AND IEC60502 600/1000V
