Braided Tough Rubber Flexible Cord - HOFR, BS6500/75, BS6007/75, PCP - 1mm to 16mm
OVERVIEW
Overview
Braided Tough rubber and flexible cord cable is suitable for installing in damp environments. It is designed for temporary building sites as the upper braiding prevents earth leakage and offers mechanical protection. Heat and oil resistant and flame retardant (HOFR). The cable features flexible stranded copper or tinned annealed copper conductors
Braided Tough rubber and flexible cord cable is suitable for installing in damp environments. It is designed for temporary building sites as the upper braiding prevents earth leakage and offers mechanical protection. Heat and oil resistant and flame retardant (HOFR). The cable features flexible stranded copper or tinned annealed copper conductors
Standards
- BS6500/75
- BS6007/75
- Flame Propagation to BS 4066 PT1
- Flame Propagation to IEC 332 PT1
Construction
Conductor: Flexible stranded copper or Tinned Annealed Copper Conductors
Insulation: Heavy duty Polychloropene (PCP)
Screen: Tinned Copper Wire Braid
Sheath: Heavy duty Polychloropene (PCP)
Sheath Colour: Black
Characteristics
Voltage Rating: 300/500 Volts
Temperature limits: -25°C to +60°C
Minimum Bending Radius: As per cable manufacturer datasheet
Should not be installed at temperatures below 0°C
