STANDARD FIRE ALARM & SECURITY CABLE - BS5839, BS7629 - 1MM TO 4MM
STANDARD FIRE ALARM & SECURITY CABLE - BS5839, BS7629 - 1MM TO 4MM



OVERVIEW

FIRE RATING 30 MINUTES
Standard fire alarm and security cable. Soft Skin Standard Fire Resistant Cables for general use in fire detection, fire alarm, voice alarm, and emergency lighting circuits.
These cables are designed to carry on working for a specific length of time under fire conditions.
‘Standard’ fire resistance is recommended for general use in low rise buildings up to 10 storeys.
STANDARDS
  • Fire Resistant to IEC 331, BS6387 & BS7629-1-2008
  • Flame Retardant to BS5839-1:2017, IEC60332-3 CAT CWZ & BS7629-1-1997
  • Acid Gas emission to BS EN 50267, IEC 60754
  • Flame propagation to BS EN 50265, BS EN 50266 & IEC 60360134
  • Smoke Emission to BS EN 50268, IEC 61034
  • Flame Propagation to BS EN 50265, BS EN 50266, IEC 60332
CONSTRUCTION

Conductor:
1.5mm2 - 2.5mm2: Class 1 solid conductor according to BS EN 60228
4mm2: Class 2 stranded conductor according to BS EN 60228
Insulation: Fire resistant MICA tape or fire resistant silicone rubber
Overall Screen: AL/PET (Aluminium/Polyester Tape), Circuit Protective Conductor, Tinned Copper
Sheath: Low Smoke Zero Halogen (LSZH)

CHARACTERISTICS

Voltage Rating: 300/500V
Temperature limits: -40°C to +90°C
Minimum Bending Radius: As Per Manufacturers Datasheet

Should not be installed at temperatures below 0°C or above +40°C

For more information please consult a member of the Cleveland Cable Sales Team


PRODUCTS

CodeDescription
FP2X12C+E X 1 SEC CABLE BS5839-1-02 RED BULK
FP2X12C+E X1 SEC CABLES RED R100 BS7629-1 BS6387C,W,Z
FP2X12C+E X 1 SEC CABLES RED 500M REEL BS7629-1 BS6387C,W,Z
FP2X12C+E X 1 SEC CABLE BS5839-1-02 WHITE BULK
FP2X12C+E X 1 SEC CABLES WHITE 100M REEL BS7629-1 BS6387C,W,Z
FP2X12C+E X 1 SEC CABLES WHITE 500M REEL BS7629-1 BS6387C,W,Z
FP3X13C+E X 1 SEC CABLE BS5839-1-02 RED BULK
FP3X13C+E X 1 SEC CABLES BS5839-1-02 RED 100M REEL
FP3X13C+E X 1 SEC CABLES BS5839-1-02 RED 500M REEL
FP3X13C+E X 1 SEC CABLE BS5839-1-02 WHITE BULK
FP3X13C+E X 1 SEC CABLES BS5839-1-02 WHITE 100M REEL
FP3X13C+E X 1 SEC CABLES BS5839-1-02 WHITE 500M REEL
FP4X14C+E X 1 SEC CABLE BS5839-1-02 RED BULK
FP4X14C+E X 1 SEC CABLES BS5839-1-02 RED 100M REEL
FP4X14C+E X 1 SEC CABLES BS5839-1-02 RED 500M REEL
FP4X14C+E X 1 SEC CABLE BS5839-1-02 WHITE BULK
FP4X14C+E X 1 SEC CABLES BS5839-1-02 WHITE 100M REEL
FP4X14C+E X 1 SEC CABLES BS5839-1-02 WHITE 500M REEL
FP7X17C X 1 SEC CABLE BS5839-1-02 RED BULK
FP7X17C X 1 SEC CABLE BS5839-1-02 WHITE BULK
FP12X112C X 1 SEC CABLE BS5839-1-02 RED BULK
FP12X112C X 1 SEC CABLE BS5839-1-02 WHITE BULK
FP2X1/52C+E X 1.5 SEC CABLE BS5839-1-02 RED BULK
FP2X1/52C+E X1.5 SEC CABLES BS5839-1-02 RED 100M REEL
FP2X1/52C+E X 1.5 SEC CABLES BS5839-1-02 RED 200M REEL
FP2X1/52C+E X 1.5 SEC CABLES BS5839-1-02 RED 500M REEL
FP2X1/52C+E X 1.5 SWA SEC CABLE BS5839-1-02 RED
FP2X1/52C+E X 1.5 SEC CABLE BS5839-1-02 WHITE BULK
FP2X1/52C+E X 1.5 SEC CABLES BS5839-1-02 WHITE 100M REEL
FP2X1/52C+E X 1.5SEC CABLES BS5839-1-02 WHITE 200M REEL
FP2X1/52C+E X 1.5 SEC CABLES BS5839-1-02 WHI 500M REEL
FP2X1/52C+E X 1.5 SEC CABLE BS5839-1-02 BLACK BULK
FP2X1/52C+E X 1.5 SEC CABLES BS5839-1-02 BLACK 100M REEL
FP2X1/52C+E X 1.5 SEC CABLES BS5839-1-02 BLACK 500M REEL
FP2X1/52C+E X 1.5 SEC CABLE BS5839-1-02 ORANGE
FP3X1/53C+E X 1.5 SEC CABLE BS5839-1-02 RED BULK
FP3X1/53C+E X 1.5 SEC CABLES BS5839-1-02 RED 100M REEL
FP3X1/53C+E X 1.5 SEC CABLE BS5839-1-02 RED R200
FP3X1/53C+E X 1.5 SEC CABLES BS5839-1-02 RED 500M REEL
FP3X1/53C+E X 1.5 SEC CABLE BS5839-1-02 WHITE BULK
FP3X1/53C+E X 1.5 SEC CABLES BS5839-1-02 WHITE 100M REEL
FP3X1/53C+E X 1.5 SEC CABLES BS5839-1-02 WHIITE 200M REELS
FP3X1/53C+E X 1.5 SEC CABLES BS5839-1-02 WHITE 500M REEL
FP4X1/54C+E X 1.5 SEC CABLE BS5839-1-02 RED BULK
FP4X1/54C+E X 1.5 SEC CABLES BS5839-1-02 RED R100
FP4X1/54C+E X 1.5 SEC CABLES BS5839-1-02 RED R200
FP4X1/54C+E X 1.5 SEC CABLES BS5839-1-02 RED R500
FP4X1/54C+E X 1.5 SWA SEC CABLE BS5839-1-02 RED
FP4X1/54C+E X 1.5 SEC CABLE BS5839-1-02 WHITE BULK
FP4X1/54C+E X 1.5 SEC CABLES BS5839-1-02 WHITE 100M REEL
FP4X1/54C+E X 1.5 SEC CABLESBS5839-1-02 WHITE 200M REEL
FP4X1/54C+E X 1.5 SEC CABLES BS5839-1-02 WHITE 500M REEL
FP4X1/54C+E X 1.5 SEC CABLE BS5839-1-02 BLACK BULK
FP4X1/54C+E X 1.5 SEC CABLES BS5839-1-02 BLACK 100M REEL
FP4X1/54C+E X 1.5 SEC CABLES BS5839-1-02 BLACK 500M REEL
FP7X1/57C+E X 1.5 SEC CABLE BS5839-1-02 RED BULK
FP7X1/57C+E X 1.5 SEC CABLES BS5839-1-02 RED 100M REEL
FP7X1/57C+E X 1.5 SEC CABLE BS5839-1-02 WHITE BULK
FP7X1/57C+E X 1.5 SEC CABLES BS5839-1-02 WHITE 100M REEL
FP7X1/57C+E X 1.5 SEC CABLE BS5839-1-02 WHITE R500
FP12X1/512C X 1.5 SEC CABLE BS5839-1-02 RED BULK
FP12X1/512C X 1.5 SEC CABLES BS5839-1-02 WHITE BULK
FP19X1/519C X 1.5 SEC CABLE BS5839-1-02 RED BULK
FP19X1/519C X 1.5 SEC CABLE BS5839-1-02 WHITE BULK
FP2X2/52C+E X 2.5 SEC CABLE BS5839-1-02 RED BULK
FP2X2/52C+E X 2.5 SEC CABLES BS5839-1-02 RED 100M REEL
FP2X2/52C+E X 2.5 SEC CABLESBS5839-1-02 RED 200M REEL
FP2X2/52C+E X 2.5 SEC CABLES BS5839-1-02 RED 500M REEL
FP2X2/52C+E X 2.5 SWA SECURITY CABLE BS7262 RED
FP2X2/52C+E X 2.5 SEC CABLE BS5839-1-02 WHITE BULK
FP2X2/52C+E X 2.5 SEC CABLES BS5839-1-02 WHI 100M REEL
FP2X2/52C+E X 2.5 SEC CABLES BS5839-1-02 WHITE 200M REEL
FP2X2/52C+E X 2.5 SEC CABLES BS5839-1-02 WHITE 500M REEL
FP3X2/53C+E X 2.5 SEC CABLE BS5839-1-02 RED BULK
FP3X2/53C+E X 2.5 SEC CABLES BS5839-1-02 RED 100M REEL
FP3X2/53C+E X 2.5 SEC CABLES BS5839-1-02 RED 500M REEL
FP3X2/53C+E X 2.5 SEC CABLE BS5839-1-02 WHITE BULK
FP3X2/53C+E X 2.5 SEC CABLES BS5839-1-02 WHITE 100M REEL
FP3X2/53C+E X 2.5 SEC CABLES BS5839-1-02 WHITE 200M REEL
FP3X2/53C+E X 2.5 SEC CABLES BS5839-1-02 WHITE 500M REEL
FP4X2/54C+E X2.5 SEC CABLE BS5839-1-02 RED BULK
FP4X2/54C+E X 2.5 SEC CABLES BS5839-1-02 RED 100M REEL
FP4X2/54C+E X 2.5 SEC CABLES BS5839-1-02 RED 500M REEL
FP4X2/54C+E X 2.5 SEC CABLE BS5839-1-02 WHITE BULK
FP4X2/54C+E X 2.5 SEC CABLES BS5839-1-02 WHI 100M REEL
FP4X2/54C+E X 2.5 SEC CABLES BS5839-1-02 WHITE 500M REEL
FP7X2/57C X 2.5 SEC CABLE BS5839-1-02 RED BULK
FP7X2/57C X 2.5 SEC CABLE BS5839 1-02 WHITE BULK
FP12X2/512C X 2.5 SEC CABLE BS5839-1-02 RED BULK
FP12X2/512C X 2.5 SEC CABLE BS5839-1-02 WHITE BULK
FP19X2/519C X 2.5 SEC CABLE BS5839-1-02 RED BULK
FP19X2/519C X 2.5 SEC CABLE BS5839-1-02 WHITE BULK
FP2X42C+E X 4 SEC CABLE BS5839-1-02 RED BULK
FP2X42C+E X 4 SEC CABLES BS5839-1-02 RED 100M REEL
FP2X42C+E X 4 SEC CABLES BS5839-1-02 RED 500M REEL
FP2X42C+E X 4 SEC CABLE BS5839-1-02 WHITE BULK
FP2X42C+E X 4 SEC CABLES BS5839-1-02 WHITE 100M REEL
FP2X42C+E X 4 SEC CABLES BS5839-1-02 WHITE 200M REEL
FP2X42C+E X 4 SEC CABLES BS5839-1-02 WHITE 500M REEL
FP3X43C+E X 4 SEC CABLE BS5839-1-02 RED BULK
FP3X43C+E X 4 SEC CABLES BS5839-1-02 RED 100M REEL
FP3X43C+E X 4 SEC CABLES BS5839-1-02 RED 500M REEL
FP3X43C+E X 4 SEC CABLE BS5839-1-02 WHITE BULK
FP3X43C+E X 4 SEC CABLES BS5839-1-02 WHITE 100M REEL
FP3X43C+E X 4 SEC CABLES BS5839-1-02 WHITE 500M REEL
FP4X44C+E X 4 SEC CABLE BS5839-1-02 RED BULK
FP4X44C+E X 4 SEC CABLES BS5839-1-02 RED 100M REEL
FP4X44C+E X 4 SEC CABLES BS5839-1-02 RED 500M REEL
FP4X44C+E X 4 SEC CABLE BS5839-1-02 WHITE BULK
FP4X44C+E X 4 SEC CABLES BS5839-1-02 WHITE 100M REEL
FP4X44C+E X 4 SEC CABLES BS5839-1-02 WHITE 500M REEL
