Enhanced Fire Alarm & Security Cable - BS5839, BS7629 - 1.5mm to 4mm
Enhanced Fire Alarm & Security Cable - BS5839, BS7629 - 1.5mm to 4mm


OVERVIEW

Enhanced fire alarm and security cable. Soft Skin enhanced Fire Resistant Cables for general use in fire detection, fire alarm, voice alarm, and emergency lighting circuits. Enhanced cables are designed to carry on working for 120 minutes in a fire.

The higher fire resistance this cable provides is recommended for systems in which cables might need to operate correctly during a fire for multiple phase evacuation such as tower blocks and multi storey buildings.
STANDARDS
  • BS 5839-1:2017 Enhanced 120
  • BS 8519:2020 Category 2
  • BS 7629-1:2015 Enhanced 120
  • BS 8434-2:2003 +A2:2009 120 minutes
    (Fire, Mechanical Shock & Water
    120 mins @930°C (water final 60 mins))
  • BS EN 50200:2015 PH30, PH60, PH120
    (Fire, Mechanical Shock & Water
    120 mins @930°C
    (water final 60 mins, MS every 5 minutes))
  • BS 6387:2013 CWZ
  • BS EN 60754-1:2014 Halogen Emission Standard
  • BE EN 61034-2:2005 + A1:2013 Low Smoke Standard
CONSTRUCTION

Conductor: Class 1 solid conductor according to BS EN 60228
Insulation: Fire resistant MICA tape or fire resistant silicone rubber
Overall Screen: AL/PET (Aluminium/ Polyester Tape), Circuit Protective Conductor, Tinned Copper
Outer Sheath: Low Smoke Zero Halogen (LSZH)

CHARACTERISTICS

Voltage Rating: 300/500V
Temperature limits: -40°C to +90°C
Minimum Bending Radius: As Per Manufacturers Datasheet

Should not be installed at temperatures below 0°C or above +40°C

PRODUCTS

CodeDescription
ENH2X1/52C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED BASEC
ENH2X1/52C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED 100M REEL BASEC
ENH2X1/52C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED 200M REEL BASEC
ENH2X1/52C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED 500M REEL BASEC
ENH2X1/52C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 WHITE BASEC
ENH2X1/52C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 WHITE 100M REEL BASEC
ENH2X1/52C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 WHITE 200M REEL BASEC
ENH2X1/52C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 WHITE 500M REEL BASEC
ENH3X1/53C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED BULK BASEC
ENH3X1/53C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED 100M REEL BASEC
ENH3X1/53C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED 200M REEL BASEC
ENH3X1/53C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED 500M REEL BASEC
ENH3X1/53C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 WHITE BULK BASEC
ENH3X1/53C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 WHITE 100M REEL BASEC
ENH3X1/53C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 WHITE 200M REEL BASEC
ENH3X1/53C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 WHITE 500M REEL BASEC
ENH4X1/54C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED BASEC
ENH4X1/54C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED 100M REEL BASEC
ENH4X1/54C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED 200M REEL BASEC
ENH4X1/54C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 RED 500M REEL BASEC
ENH4X1/54C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 WHITE 100M REEL BASEC
ENH4X1/54C+E X 1.5 SEC CABLE ENHANCED BS5839-1-02 WHITE 500M REEL BASEC
ENH2X2/52C+E X 2.5 SEC CABLE ENHANCED BS5839-1-02 RED BASEC
ENH2X2/52C+E X 2.5 SEC CABLE ENHANCED BS5839-1-02 RED 100M REEL BASEC
ENH2X2/52C+E X 2.5 SEC CABLE ENHANCED BS5839-1-02 RED 500M REEL BASEC
ENH2X2/52C+E X 2.5 SEC CABLE ENHANCED BS5839-1-02 WHITE BASEC
ENH2X2/52C+E X 2.5 SEC CABLE ENHANCED BS5839-1-02 WHITE 100M REEL BASEC
ENH2X2/52C+E X 2.5 SEC CABLE ENHANCED BS5839-1-02 WHITE 500M REEL BASEC
ENH3X2/53C+E X 2.5 SEC CABLE ENHANCED BS5839-1-02 RED BULK BASEC
ENH3X2/53C+E X 2.5 SEC CABLE ENHANCED BS5839-1-02 WHITE BULK BASEC
ENH4X2/54C+E X 2.5 SEC CABLE ENHANCED BS5839-1-02 RED BULK BASEC
ENH4X2/54C+E X 2.5 SEC CABLE ENHANCED BS5839-1-02 WHITE BULK BASEC
ENH2X42C+E X 4 SEC CABLE ENHANCED BS5839-1-02 RED BASEC
ENH2X42C+E X 4 SEC CABLE ENHANCED BS5839-1-02 RED 100M REEL BASEC
ENH2X42C+E X 4 SEC CABLE ENHANCED BS5839-1-02 RED 200M REEL BASEC
ENH2X42C+E X 4 SEC CABLE ENHANCED BS5839-1-02 RED 500M REEL BASEC
ENH2X42C+E X 4 SEC CABLE ENHANCED BS5839-1-02 WHITE BASEC
ENH2X42C+E X 4 SEC CABLE ENHANCED BS5839-1-02 WHITE 100M REEL BASEC
ENH2X42C+E X 4 SEC CABLE ENHANCED BS5839-1-02 WHITE 500M REEL BASEC
ENH3X43C+E X 4 SEC CABLE ENHANCED BS5839-1-02 RED BULK BASEC
ENH3X43C+E X 4 SEC CABLE ENHANCED BS5839-1-02 WHITE BULK BASEC
ENH4X44C+E X 4 SEC CABLE ENHANCED BS5839-1-02 RED BULK BASEC
ENH4X44C+E X 4 SEC CABLE ENHANCED BS5839-1-02 WHITE BULK BASEC
