6941AX Mains Cable 3.3kV - BS5467, AWA, XLPE - 120mm to 630mm
OVERVIEW
6941AX 3.3kV mains cable. Single core aluminium wire armoured cable most commonly used in power networks, due to the armour providing mechanical protection. Designed for use in AC circuits, the aluminium armour prevents magnetic build up and the PVC outer sheath protects the cable.
STANDARDS
- BS5467
- Flame propagation to BS EN 60332-1-2
CONSTRUCTION
Conductor: Stranded Plain Annealed Copper Conductor
Insulation: Cross Linked Polyethylene (XLPE)
Bedding: PVC
Armouring: Aluminium Wire Armour
Sheath: PVC
CHARACTERISTICS
Voltage Rating: 1900/3300 Volts
Temperature limits: -15°C to +90°C
Minimum Bending Radius: As per cable manufacturer datasheet
Should not be installed at temperatures below 0°C or above +60°C
