6181X Single Core Cathodic Protection Cable - XLPE, Non-Armoured, PVC - 6mm to 185mm
6181X Single Core Cathodic Protection Cable - XLPE, Non-Armoured, PVC - 6mm to 185mm


OVERVIEW

IEC 60502 6181X is a single core non armoured cathodic protection PVC cable, used for protection against corrosion in cathodic systems where the risk of mechanical damage is minimal.
STANDARDS
  • IEC 60502
CONSTRUCTION

Conductor: Plain Annealed Stranded Circular Copper Conductor, single core
Insulation: Cross Linked Polyethylene (XLPE)
Sheath: PVC

CHARACTERISTICS

Voltage Rating: 600/1000
Volts Temperature Rating: -15°C to + 90°C
Minimum Bending Radius: As Per Manufacturers Datasheet

Should not be installed at temperatures below 0°C or above +60°C

PRODUCTS


CodeDescription
6181X61X6 CU,XLPE,PVC,RED/RED,1KV,IEC60502
6181X61X6 CU,XLPE,PVC,BLACK/BLACK,1KV,IEC60502
6181X101X10 CU,XLPE,PVC,BLUE/BLUE,1KV IEC60502
6181X101X10 CU,XLPE,PVC,RED/RED,1KV IEC60502-2
6181X101X10 CU,XLPE,PVC,BLACK/BLACK,1KV,IEC60502
6181X161X16 CU,XLPE,PVC,RED/RED,1KV,IEC60502
6181X161X16 CU,XLPE,PVC,BLACK/BLACK,1KV,IEC60502
6181X251X25 CU,XLPE,PVC,RED/RED,1KV,IEC60502
6181X251X25 CU,XLPE,PVC BLACK/BLACK,1KV,IEC60502
6181X351X35 CU,XLPE,PVC,RED/RED,1KV,IEC60502
6181X351X35 CU,XLPE,PVC BLACK/BLACK,1KV,IEC60502
6181X501X50 CU,XLPE,BRN,PVC,BLK,1KV,BS7889/12
6181X701X70 CU,XLPE,BRN,PVC,BLK,1KV,BS7889/12
6181X951X95 CU,XLPE,BRN,PVC,BLK,1KV,BS7889/12
6181X1201X120 CU,XLPE,BRN,PVC,BLK,1KV,BS7889/12
6181X1501X150 CU,XLPE,BRN,PVC,BLK,1KV,BS7889/12
6181X1851X185 CU,XLPE,BRN,PVC,BLK,1KV,BS7889/12
