F120 Enhanced Fire Resistant Mains Cable 1kV - BS7846, BS8491, MGT, XLPE, SWA, LSZH - 4mm to 16mm
F120 Enhanced Fire Resistant Mains Cable 1kV - BS7846, BS8491, MGT, XLPE, SWA, LSZH - 4mm to 16mm


OVERVIEW

Fireproof mains cable, suitable for fixed installations such as power circuits, fire alarm systems and emergency lighting. Specifically designed to meet the stringent standards of BS8491, which includes enhanced resistance to heat and fire, direct impact of 10N and water jet as would be produced by a fire fighting unit.
CABLE STANDARDS
  • Conforms to BS7846/ BS8491
  • Conforms to BS 6387, BS EN 50267, BS EN 50268
  • Circuit integrity: BS8519-2020 120 minutes
  • Acid gas emission to IEC 60754
  • Flame propagation to BS EN 50265,
  • BS EN 50266 (IEC 60332-3).
  • Smoke emission to IEC 61034
  • LPCB Approved
CONSTRUCTION

Conductor: Plain Annealed Stranded Copper Conductor
Separator: MICA/Glass Fire Barrier Tape
Insulation: Cross Link Polyethylene (XLPE)
Bedding: LSZH
Armouring: Galvanised Steel Wire Armour
Sheath: Low Smoke Zero Halogen (LSZH)
Sheath Colour: Black

CHARACTERISTICS

Voltage Rating: 600/1000 volts
Temperature limits: -10°C to +90°C
Minimum Bending Radius: As Per Manufacturers Datasheet

PRODUCTS


CodeDescription
FPE2X42X4 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK BASEC/LPCB APPROVED
FPE3X43X4 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BASEC/LPCB APPROVED
FPE4X44X4 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BLUE BASEC/LPCB APPROVED
FPE5X45X4 MICA, XL, LZH, SWA , LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BLUE GREEN/YELLOW
FPE2X62X6 MICA,XL,LZH,SWA,LZH ENHHANCED 1KV BS7846, BS8491,BS8519 CORES BRN BLK BASEC/LPCB APPROVED
FPE3X63X6 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BASEC/LPCB APPROVED
FPE4X64X6 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BLUE BASEC/LPCB APPROVED
FPE5X65X6 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BLUE GREEN/YELLOW
FPE2X102X10 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK BASEC/LPCB APPROVED
FPE3X103X10 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BASEC/LPCB APPROVED
FPE4X104X10 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BLUE BASEC/LPCB APPROVED
FPE5X105X10 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BLUE BASEC/LPCB APPROVED
FPE2X162X16 MICA,XL,LZH,SWA,LZH ENHHANCED 1KV BS7846, BS8491,BS8519 CORES BRN BLK BASEC/LPCB APPROVED
FPE3X163X16 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BASEC/LPCB APPROVED
FPE4X164X16 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BLUE BASEC/LPCB APPROVED
FPE5X165X16 MICA,XL,LZH,SWA,LZH ENHANCED 1KV BS7846,BS8491,BS8519 CORES BRN BLK GREY BLUE BASEC/LPCB APPROVED
