NHXMH-J Domestic & Industrial Cable - BSEN60332-3-24, LSZH - 1.5mm to 10mm
NHXMH-J Domestic & Industrial Cable - BSEN60332-3-24, LSZH - 1.5mm to 10mm


OVERVIEW

LZSH wiring cable, indoor and outdoor use, suitable for industrial or domestic applications and designed for dry, moist or wet areas i.e. under plaster and in concrete. Not suitable for exposure to direct sunlight.
STANDARDS
  • VDE0250-214
  • BS EN 60332-3-24
CONSTRUCTION

Conductor: Up to 10mm2 - solid copper (Class 1) | 16mm2 - stranded copper (Class 2)
Insulation: XLPE
Filler: Halogen Free Compound
Sheath: Halogen free thermoplastic polymer compound
Sheath Colour: Grey

CHARACTERISTICS

Voltage Rating: 300/500Volts
Temperature Limits: -10°C to +70°C
Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed at temperatures below 0°C

PRODUCTS

CodeDescription
NHXMHJ3X1/53X1.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,GREEN/YELLOW 100M REEL
NHXMHJ3X1/53X1.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,GREEN/YELLOW 500M REEL
NHXMHJ4X1/54X1.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLACK, GREY,GREEN/YELLOW 100M REEL
NHXMHJ4X1/54X1.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLACK, GREY,GREEN/YELLOW 500M REEL
NHXMHJ5X1/55X1.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,BLACK, GREY,GREEN/YELLOW 100M REEL
NHXMHJ5X1/55X1.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,BLACK, GREY,GREEN/YELLOW 500M REEL
NHXMHJ7X1/57X1/5 SOLID COPPER CONDUCTOR, CLASS1,XLPE,LSZH,LSZH, GREY SHEATH,300/500V EN50265-2-1, NUMBERED CORES
NHXMHJ7X1/57X1.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, BLACK CORES, WHITE NUMBERS WITH GRN/YLW 100M REEL
NHXMHJ12X1/512X1/5 SOLID COPPER CONDUCTOR, CLASS1,XLPE,LSZH,LSZH, GREY SHEATH,300/500V EN50265-2-1, NUMBERED CORES
NHXMHJ3X2/53X2.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,GREEN/YELLOW 100M REEL
NHXMHJ3X2/53X2.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,GREEN/YELLOW 500M REEL
NHXMHJ5X2/55X2.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,BLACK, GREY,GREEN/YELLOW 100M REEL
NHXMHJ5X2/55X2.5 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,BLACK, GREY,GREEN/YELLOW 500M REEL
NHXMHJ3X43X4 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,GREEN/YELLOW 100M REEL
NHXMHJ3X43X4 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,GREEN/YELLOW 500M REEL
NHXMHJ5X45X4 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,BLACK, GREY,GREEN/YELLOW 100M REEL
NHXMHJ5X45X4 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,BLACK, GREY,GREEN/YELLOW 500M REEL
NHXMHJ3X63X6 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,GREEN/YELLOW 100M REEL
NHXMHJ3X63X6 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,GREEN/YELLOW 500M REEL
NHXMHJ5X65X6 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,BLACK, GREY,GREEN/YELLOW 100M REEL
NHXMHJ5X65X6 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,BLACK, GREY,GREEN/YELLOW 500M REEL
NHXMHJ3X103X10 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,GREEN/YELLOW
NHXMHJ5X105X10 SOLID COPPER CONDUCTOR, CLASS1, XLPE,LSZH,LSZH, GREY SHEATH,300/500V BS EN60332-3-24, VDE0250-214, CORES BROWN,BLUE,BLACK, GREY,GREEN/YELLOW
