Straight Concentric Cable 1kV - BS7870, ESI 09-7, PVC - 4mm to 35mm
OVERVIEW
Used by Distribution Network Operators (DNO’s) such as UKPN, WPD, ENW, NPG, SSE etc. Straight concentric cable is normally used as an energy supply cable most commonly found in power station distribution, panel boards and street lighting areas where mechanical protection is required.
STANDARDS
- BS7870 - 3.11
- BS EN 60228
CONSTRUCTION
Conductor: Stranded Copper Conductor
Insulation: Poly Vinyl Chloride (PVC)
Concentric Conductor: Plain Copper wires
Sheath: Poly Vinyl Chloride (PVC)
Sheath Colour: Black
CHARACTERISTICS
Voltage Rating: 600/1000 volts
Temperature Limits: -15°C to +70°C
Minimum Bending Radius: As per cable manufacturer datasheet
Should not be installed at temperatures below 0°C or above +60°C
