BS7870 Triplex Aluminium Power Cable 11kV - XLPE, MDPE - 70mm to 300mm
OVERVIEW
Medium voltage aluminium power cable for connections from electrical grid to sub-main developments. Suitable for power networks, underground, outdoors and installation in cable ducting.
STANDARDS
- BS7870 4.10
- UV Stabilised
CONSTRUCTION
Conductor: Stranded Aluminium Conductors
Insulation: Cross Link Polyethylene (XLPE)
Metallic Screen: Copper Wires plus copper tape
Sheath: Medium Density Polyethylene (MDPE)
Sheath Colour: Red
CHARACTERISTICS
Voltage Rating: 11000V
Temperature Limits: -15°C to +90°C
Minimum Bending Radius: As per cable manufacturer datasheet
Should not be installed at temperatures below 0°C
