N2XH Class 5 Flexible LSZH LV Power Cable KEMA Approved
N2XH Class 5 Flexible LSZH LV Power Cable KEMA Approved


OVERVIEW

The N2XH Class 5 Low Voltage (LV) Flexible Power Cable is a KEMA-approved, high-performance solution for safe and efficient power distribution. Featuring a Low Smoke Zero Halogen (LSZH) sheath, it reduces toxic smoke and emissions in fire scenarios, making it ideal for use in public spaces, commercial buildings, and industrial environments.

This flexible, non-armoured cable is designed for easy installation and meets international safety standards, ensuring reliable and durable performance in demanding applications. Available in various sizes, it is perfect for low-voltage fixed wiring and power distribution projects.

Choose N2XH LSZH Flexible Power Cables for trusted safety, compliance, and efficiency in critical installations. Perfect for professionals seeking premium-quality cables with global approvals. This cable is not suitable for direct burial.
Standards
  • IEC 60502-1
  • IEC 60288
  • Fire retardant to IEC 60332-3-24 Cat C
  • Halogen free to IEC60754-1 & 2
  • Low smoke to IEC 61034-2
  • IEC 60332-1
  • KEMA Approved
Construction

Conductor: Flexible class 5 stranded copper
Insulation: Cross linked Polyethylene (XPLE)
Filler: Low Smoke Zero Halogen (LSZH)
Sheath: Low Smoke Zero Halogen (LSZH)

Characteristics

Voltage Rating: 600/1000 Volts
Temperature Limits: +90°C
Minimum Bending Radius: 5 x overall diameter

PRODUCTS


CodeDescription
N2XHK1X1/51X1.5 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK3X1/53X1.5 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X1/54X1.5 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK5X1/55X1.5 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X2/51X2.5 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK3X2/53X2.5 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X2/54X2.5 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK5X2/55X2.5 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X41X4 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK3X43X4 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X44X4 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK5X45X4 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X61X6 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK3X63X6 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X64X6 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK5X65X6 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X101X10 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK3X103X10 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X104X10 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK5X105X10 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X161X16 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK3X163X16 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X164X16 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK5X165X16 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X251X25 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK3X253X25 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X254X25 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK5X255X25 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X351X35 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK3X353X35 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X354X35 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK5X355X35 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X501X50 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK3X503X50 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X504X50 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK5X505X50 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X701X70 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X704X70 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK5X705X70 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X951X95 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X954X95 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X1201X120 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X1204X120 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X1501X150 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X1504X150 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X1851X185 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X1854X185 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X2401X240 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X2404X240 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X3001X300 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK4X3004X300 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X4001X400 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
N2XHK1X5001X500 N2XH CLASS 5 LSZH LV POWER CABLE KEMA APPROVED
