BS5467 3 Core Mains Cable 3.3kV - XLPE, SWA, PVC - 16mm to 400mm
OVERVIEW
Cleveland Cable Company stocks a large range of 3.3KV (3300V) 3 core mains cable available in sizes 16mm to 400mm and manufactured to British Standard BS5467. The 3 core mains cable is a medium voltage power cable designed to be buried for installation. The cable can also be used indoors and outdoors and in cable ducting.
STANDARDS
- BS 5467
- Flame propagation: BS EN/IEC 60332
CONSTRUCTION
Conductor: Class 2 stranded copper conductor acc BS EN 60228 (previously BS 6360)
Insulation: Cross Link Polyethylene (XLPE)
Bedding: Polyvinyl Chloride (PVC)
Armour: Steel Wire Armour (SWA)
Sheath: Polyvinyl Chloride PVC
CHARACTERISTICS
Voltage Rating: 1900/3300 Volts
Temperature Rating: Fixed -20°C to +90°C
Minimum Bending Radius: As Per Manufacturers Datasheet
Should not be installed at temperatures below 0°C or above +60°C
