OVERVIEW

General single core control / power cable for fixed wiring arrangements and power networks. Suitable for underground, indoor and outdoor use in cable ducting. This cable is BASEC approved.

STANDARDS
  • BS 5467
  • Flame propagation: BS EN 60332-1-2
  • BASEC Approved
CONSTRUCTION

Conductor: Stranded Plain Annealed Circular Copper Conductor
Insulation: Cross Linked Polyethlene (XLPE)
Bedding: PVC
Armouring: Aluminium Wire Armour (AWA)
Sheath: PVC

CHARACTERISTICS

Voltage Rating: 1900/3300 Volts
Temperature Rating: Fixed -20°C to +90°C
Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed at temperatures below 0°C or above +60°C

PRODUCTS

CodeDescription
6941AX501X50 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV
6941AX701X70 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV
6941AX951X95 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV
6941AX1201X120 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV BASEC
6941AX1501X150 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV BASEC
6941AX1851X185 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV BASEC
6941AX2401X240 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV BASEC
6941AX3001X300 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV BASEC
6941AX4001X400 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV
6941AX5001X500 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV BASEC
6941AX6301X630 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV
6941AX8001X800 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV BASEC
6941AX10001X1000 CU,XLPE,BROWN,PVC,AWA,PVC,BLACK,BS5467 1KV BASEC
