Utility Industry Control Cable - SWA, PVC
Utility Industry Control Cable - SWA, PVC


OVERVIEW

This is a utility industries multicore control cable that is mainly used in substations and power stations. The cable is manufactured to specification ENATS 09-6 (Electrical National Association and Technical specification). ENATS is the governing body who cover utilities specification cables.
Standards
  • ENATS 09-6: Issue 8 Section 3.6
  • BS7870-8.1:2003
  • Flame retardant to IEC 60332-3-24c
Construction

Conductor: Stranded Plain Annealed Copper Conductors
Insulation: Polyvinyl Chloride (PVC)
Bedding: Polyvinyl Chloride (PVC)
Armouring: Galvanised Steel Wire Armour
Sheath: PVC
Sheath Colour: Black

Characteristics

Voltage Rating: 600/1000 Volts
Temperature Limits: -30°C to +70°C
Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed at temperatures below 0°C or above +40°C

PRODUCTS

CodeDescription
6942X2/5ESI2X2.5(7) PVC,PVC,SWA,PVC,ESI, WHITE CORES, BLACK NOS BS 7870-8.1:2003
6943X2/5ESI3X2.5(7) PVC,PVC,SWA,PVC,ESI, WHITE CORES, BLACK NOS BS 7870-8.1:2003
6944X2/5ESI4X2.5(7) PVC,PVC,SWA,PVC,ESI, WHITE CORES, BLACK NOS BS 7870-8.1:2003
6947X2/5/77X2.5(7) PVC,PVC,SWA,PVC 1KV WHITE CORES, BLACK NOS BS 7870-8.1:2003
6940/12X2/5/712X2.5(7) PVC,PVC,SWA,PVC 1KV WHITE CORES, BLACK NOS BS 7870-8.1:2003
6940/19X2/5/719X2.5(7) PVC,PVC,SWA,PVC 1KV WHITE CORES, BLACK NOS BS 7870-8.1:2003
6940/27X2/5/727X2.5(7) PVC,PVC,SWA,PVC 1KV WHITE CORES, BLACK NOS BS 7870-8.1:2003
6940/37X2/5/737X2.5(7) PVC,PVC,SWA,PVC 1KV WHITE CORES, BLACK NOS BS 7870-8.1:2003
