Railway Power Cable - Aluminium, XLPE, PVC - 16mm to 95mm
Railway Power Cable - Aluminium, XLPE, PVC - 16mm to 95mm


OVERVIEW

The rail power cables are most commonly used as the main power supply cable for signalling along the rail tracks. The aluminium conductors are generally used for primary and secondary power distribution conductors.
Standards
  • BS5467
  • BR880 06/142639
Construction

Conductor: Solid Plain Aluminium Sectoral Conductors
Insulation: Cross Linked Polyethylene (XLPE)
Sheath: Polyvinyl Chloride (PVC)
Sheath Colour: Black

Characteristics

Voltage Rating: 600/1000 volts
Temperature limits: -25°C to +90°C
Minimum Bending Radius: As Per Manufacturers Datasheet

PRODUCTS


CodeDescription
SAC2X16NA2X16 SOL ALM XLPE PVC 1KVBR880 06/142419
SAC2X25NA2X25 SOLALM XLPE PVC 1KV BR880 06/142519
SAC2X35NA2X35SOL ALM XLPE PVC 1KV BR880 06/142609
SAC2X50NA2X50 SOL ALM XLPE PVC 1KVBR880 06/142629
SAC2X70NA2X70SOL ALM XLPE PVC 1KV BR880 06/142639
SAC2X95NA2X95SOL ALM XLPE PVC 1KV BR880 06/142644
SAC4X70NA4X70 SOL ALM XLPE PVC 1KVBR880 06/151469
