638*TQ Flexible Mains Cable - EPR, CSP - 25mm to 630mm
638*TQ Flexible Mains Cable - EPR, CSP - 25mm to 630mm


OVERVIEW

Overview
Our range of flexible TQ cables is designed for fixed wiring installations. It is a range of unarmoured cable designed to prevent the risk of electric shock in the event of fault or surge. Our TQ cable is suitable as a flexible marine cable, both on and offshore. This range of 300/750V (refer to core size in Characteristics) is heat and oil resistant, and flame retardant (HOFR).

Datasheet must be used in conjunction with 18th edition IET wiring regulations.
STANDARDS
  • BS EN 50525-2-21
  • BS EN 60332-1-2
CONSTRUCTION

Conductor: Flexible tinned annealed or plain copper conductor
Insulation: EPR (Ethylene Propylene Rubber)
Sheath: CSP (chlorosulphonated polyethylene)
Harmonised Code: H07BN4-F

CHARACTERISTICS

Voltage Rating:
300/500V: 0.75mm2 – 2.5mm2
450/750V: 4mm2 – 630mm2
Temperature Rating: Fixed -25°C to +90°C
Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed at temperatures below: -25°C

PRODUCTS

CodeDescription
6381TQ251X25 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 12.7 - 15.8
6381TQ251X25 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6382TQ252X25 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6383TQ253X25 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ254X25 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6385TQ255X25 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ351X35 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 14.3 - 17.9
6381TQ351X35 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6382TQ352X35 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6383TQ353X35 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ354X35 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6385TQ355X35 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ501X50 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 16.5 - 20.6
6381TQ501X50 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6383TQ503X50 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ504X50 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6385TQ505X50 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ701X70 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 18.6 - 23.3
6381TQ701X70 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6383TQ703X70 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ704X70 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6385TQ705X70 EPR CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ951X95 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 20.8 - 26.0
6381TQ951X95 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6383TQ953X95 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ954X95 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACKTINNED COPPER CONDUCTORS
6385TQ955X95 EPR CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ1201X120 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 22.8 - 28.6
6383TQ1203X120 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ1204X120 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6385TQ1205X120 EPR CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ1501X150 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 25.2 - 31.4
6383TQ1503X150 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ1504X150 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ1851X185 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 27.6 - 34.4
6381TQ1851X185 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6383TQ1853X185 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ1854X185 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ2401X240 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 30.6 - 38.3
6381TQ2401X240 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6383TQ2403X240 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ2404X240 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ3001X300 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 33.5 - 41.9
6381TQ3001X300 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6383TQ3003X300 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ3004X300 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ4001X400 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 37.4 - 46.8
6381TQ4001X400 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6381TQ5001X500 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 41.3 - 52.0
6381TQ5001X500 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6381TQ6301X630 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 45.5 - 57.0
6381TQ6301X630 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
