638*TQ Flexible Mains Cable - EPR, CSP - 4mm to 16mm
638*TQ Flexible Mains Cable - EPR, CSP - 4mm to 16mm



OVERVIEW

Overview
Our range of flexible TQ cables is designed for fixed wiring installations. It is a range of unarmoured cable designed to prevent the risk of electric shock in the event of fault or surge. Our TQ cable is suitable as a flexible marine cable, both on and offshore. This range of 300/750V (refer to core size in characteristics) is heat and oil resistant, and flame retardant (HOFR).

Datasheet must be used in conjunction with 18th edition IET wiring regulations.
STANDARDS
  • BS EN 50525-2.21
  • BS EN 60332-1-2
CONSTRUCTION

Conductor: Flexible tinned annealed or plain copper conductor
Insulation: EPR (Ethylene Propylene Rubber)
Sheath: CSP (chlorosulphonated polyethylene)
Harmonised Code: H07BN4-F

CHARACTERISTICS

Voltage Rating:
300/500V: 0.75mm2 – 2.5mm2
450/750V: 4mm2 – 630mm2
Temperature Rating: Fixed -25°C to +90°C
Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed at temperatures below: -25°C

PRODUCTS

CodeDescription
6381TQ41X4 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6382TQ42X4 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6383TQ43X4 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ44X4 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6385TQ45X4 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6387TQ47X4 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ61X6 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 7.9 - 9.8
6381TQ61X6 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6382TQ62X6 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6383TQ63X6 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ64X6 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6385TQ65X6 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6387TQ67X6 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6388TQ68X6 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ101X10 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 9.5 - 11.9
6381TQ101X10 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6382TQ102X10 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6383TQ103X10 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ104X10 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6385TQ105X10 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6381TQ161X16 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS - O.D 10.8 - 13.4
6381TQ161X16 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F GREEN/YELLOW
6382TQ162X16 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6383TQ163X16 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6384TQ164X16 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
6385TQ165X16 EPR,CSP FLEX BS-EN 50525-2-21/H07BN4-F BLACK TINNED COPPER CONDUCTORS
