OVERVIEW

SY control cable is used as a control cable in areas requiring light mechanical protection and areas where there is risk to life from fire, smoke emissions and toxic fumes. The cables are designed to be used as a connecting cable for measuring, control and regulation equipment in assembly, production line and conveyor systems.

STANDARDS
  • Generally to BS EN 50525-3-11
  • VDE 0250
  • CY, SY and YY Cables are thoroughly tested under BSI kitemark KM712695 in our accredited lab prior to delivery
  • The lab is audited by BSI as an independent 3rd party to verify that the testing procedures and the cable meet the standards and are fit for purpose
CONSTRUCTION

Conductor: Plain Annealed Stranded Copper Conductors
Insulation: LSZH insulated
Armouring: Galvanised Steel Wire Armour
Sheath: LSZH
Sheath Colour: Grey

CHARACTERISTICS

Voltage Rating: 300/500 volts
Temperature Limits:
Static: -20°C to +80°C
Flexing: -5°C to +70°C
Minimum Bending Radius: As Per Manufacturers Datasheet

Should not be installed at temperatures below -5°C

PRODUCTS


CodeDescription
SY7X1LSF7X1 LSZH,LSZH,GSWB,LSZH CONTROL FLEX SY GREY SHEATH, BLACK CORES WHITE NUMBERS 1 GREEN/YELLOW GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY3X1/5LSF3X1.5 LSZH,LSZH,GSWB,LSZH CONTROL FLEX SY BLACK CORES, WHITE NUMBERS 1 GREEN/YELLOW, BLACK SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY3X1/5LSFCC3X1.5 LSZH, LSZH, GSWB, LSZH SY FLEX COLOURED CODED CORES GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY4X1/5LSF4X1.5 PVC,PVC,GSWB,PVC CONTROL FLEX SY TRANSPARENT,BLACK CORES, WHITE NUMBERS 1 GREEN/YELLOW GEN TO BS EN 50525-2-11/VDE0250 300/500V
SY4X1/5LSFCC4X1.5 LSZH, LSZH, GSWB, LSZH SY FLEX COLOURED CODED CORES GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250, BROWN,BLACK,GREY, GRN/YEL 300/500V
SY5X1/5LSFCC5X1.5 LSZH, LSZH, GSWB, LSZH, SY FLEX COLOUR CODED CORES, GREY SHEATH, GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY7X1/5LSF7X1.5 LSZH,LSZH,GSWB,LSZH CONTROL FLEX SY BLACK CORES, WHITE NUMBERS 1 GREEN/YELLOW, GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY12X1/5LSF12X1.5 LSZH,LSZH,GSWB,LSZH CONTROL FLEX SY BLACK CORES, WHITE NUMBERS 1 GREEN/YELLOW, GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY3X2/5LSF3X2.5 LSZH,LSZH,GSWB,LSZH CONTROL FLEX SY BLACK CORES, WHITE NUMBERS 1 GREEN/YELLOW, BLACK SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY3X2/5LSFCC3X2/5 LSZH, LSZH, GSWB, LSZH, SY FLEX COLOUR CODED CORES, GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY4X2/5LSF4X2.5 LSZH,LSZH,GSWB,LSZH CONTROL FLEX SY BLACK CORES, WHITE NUMBERS 1 GREEN/YELLOW, BLACK SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY4X2/5LSFCC4X2/5 LSZH, LSZH, GSWB, LSZH, SY FLEX COLOUR CODED CORES, GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY5X2/5LSFCC5X2/5 LSZH, LSZH, GSWB, LSZH, SY FLEX COLOUR CODED CORES, GREY SHEATH, GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY7X2/5LSF7X2.5 LSZH,LSZH,GSWB,LSZH CONTROL FLEX SY BLACK CORES, WHITE NUMBERS 1 GREEN/YELLOW, GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY3X4LSFCC3X4 LSZH, LSZH, GSWB, LSZH SY FLEX COLOURED CODED CORES GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY4X4LSFCC4X4 LSZH, LSZH, GSWB, LSZH, SY FLEX COLOUR CODED CORES, GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY5X4LSFCC5X4 LSZH, LSZH, GSWB, LSZH SY FLEX COLOURED CODED CORES GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY3X6LSF3X6 LSZH LSZH GSWB LSZH CONTROL FLEX SY,BLACK CORES, WHITE NUMBERS 1 GREEN/YELLOW, BLACK SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY3X6LSFCC3X6 LSZH,LSZH,GSWB,LSZH SY FLEX COLOUR CODED CORES GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY4X6LSFCC4X6 LSZH, LSZH, GSWB, LSZH SY FLEX COLOURED CODED CORES GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY5X6LSFCC5X6.0 LSZH, LSZH, GSWB, LSZH, SY FLEX COLOUR CODED CORES, GREY SHEATH, GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY4X10LSFCC4X10 LSZH,LSZH,GSWB,LSZH CONTROL FLEX SY GREY SHEATH, BLACK,BROWN,GREY, GREEN/YELLOW GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY5X10LSFCC5X10 LSZH, LSZH, GSWB, LSZH, SY FLEX COLOUR CODED CORES, GREY SHEATH, GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY4X16LSFCC4X16 LSZH,LSZH,GSWB,LSZH CONTROL FLEX SY GREY SHEATH, BLACK,BROWN,GREY, GREEN/YELLOW GEN TO BS EN 50525-3-11/VDE0250 300/500V
SY5X16LSFCC5X16 LSZH, LSZH, GSWB, LSZH, SY FLEX COLOURED CORES BR, BU, BK, GY, EY. GREY SHEATH GEN TO BS EN 50525-3-11/VDE0250 300/500V
