Northern Powergrid Approved Triplex Cable - 11kV, XLPE, MDPE - 95mm-300mm
Northern Powergrid Approved Triplex Cable - 11kV, XLPE, MDPE - 95mm-300mm


OVERVIEW

Overview
NPG approved medium voltage aluminium power cable for connections from electrical grid to sub-main developments. Suitable for power networks, underground, outdoors and installation in cable ducting.
Standards
  • BS7870 4.10
  • BS EN 60228
  • UV Stablised
  • DNO Cable approved for NPG Use
Construction

Conductor: Stranded Aluminium Conductors
Insulation: Cross Link Polyethylene (XLPE)
Metallic Screen: Copper Wires and Tape
Water Blocking: Tape, Helically applied
Sheath: Medium Density Polyethylene (MDPE)
Sheath Colour: Red

Characteristics

Voltage Rating: 6350V/11000V (12KV)
Temperature limits: 0°C to +90°C
Minimum Bending Radius: As Per Manufacturers Datasheet

Should not be installed at temperatures below 0°C

PRODUCTS

CodeDescription
NPG11KVTRIP3X95AL3X1X95/35 LSXHIOE 6.35/11KV/Northern Power Grid Approved/Service Cables/Concentric Cables/Aluminium Power Cable/Domestic/Industrial/Power NetworksAdd to Quote
NPG11KVTRIP3X185AL3X1X185/35 LSXHIOE 6.35/11KV/Northern Power Grid Approved/Service Cables/Concentric Cables/Aluminium Power Cable/Domestic/Industrial/Power NetworksAdd to Quote
NPG11KVTRIP3X300AL3X1X300/35 LSXHIOE 6.35/11KV/Northern Power Grid Approved/Service Cables/Concentric Cables/Aluminium Power Cable/Domestic/Industrial/Power Networks
