SSE Approved Power Cable - 11kV, XLPE, LLDPE - 95mm to 300mm
SSE Approved Power Cable - 11kV, XLPE, LLDPE - 95mm to 300mm



OVERVIEW

Overview
SSE approved medium voltage aluminium power cable for connections from electrical grid to sub-main developments. Suitable for power networks, underground, outdoors and installation in cable ducting.

Please note: the red outer sheath can be prone to fading when exposed to UV rays.
Standards
  • BS 7870 4.20
  • BS EN 60228
  • Flame propagation to BS EN60332
  • DNO approved for SSE
Construction

Conductor: Class 2 Stranded Circular Compacted Aluminium Conductor
Screen: Fully Bonded Semi-conductive Compound
Insulation: Cross Link Polyethylene (XLPE)
Insulation Screen: Semi-conductive Compound
Screen: Copper Wires & Helical Equalising Copper Tape
Separator: Binding Tape Helically Applied
Sheath: Linear Low-Density Polyethlyene (LLDPE)
Sheath Colour: Red

Characteristics

Voltage Rating: 6350/11000 Volts (11kV)
Temperature Limits: -15ºC to 90ºC
Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed at temperatures below 0ºC or above +60ºC

PRODUCTS

CodeDescription
SSE11KVLLDPE3X95ALSSE BS7870 4.20 11KV LLDPE XLPE ALU 3X95/SSE Approved/Medium Voltage/Aluminium/Power Cables/Service Cables/Electrical Grid/Sub-Main Developments/Power Networks
SSE11KVLLDPE3X150ALSSE BS7870 4.20 11KV LLDPE XLPE ALU 3X150/SSE Approved/Medium Voltage/Aluminium/Power Cables/Service Cables/Electrical Grid/Sub-Main Developments/Power Networks
SSE11KVLLDPE3X240ALSSE BS7870 4.20 11KV LLDPE XLPE ALU 3X240/SSE Approved/Medium Voltage/Aluminium/Power Cables/Service Cables/Electrical Grid/Sub-Main Developments/Power Networks
SSE11KVLLDPE3X300ALSSE BS7870 4.20 11KV LLDPE XLPE ALU 3X300/SSE Approved/Medium Voltage/Aluminium/Power Cables/Service Cables/Electrical Grid/Sub-Main Developments/Power Networks
