CONNECTEV H07BZ5-F ELECTRIC VEHICLE CHARGING CABLE
CONNECTEV H07BZ5-F ELECTRIC VEHICLE CHARGING CABLE


OVERVIEW

This flexible cable is for use in the provision of vehicle power from consumer side units (Charging mode 1) European standard electric vehicle AC commercial and public installations (Charging mode 2 and 3). The cable is suitable for direct installation to the charging point or as a trailing EV plug that is carried in the vehicle.

STANDARDS
  • EN 50620
  • IEC 62893
  • EN/IEC 60228
  • IEC60332-1-2
  • IEC 61851-1
CONSTRUCTION

Conductor: Class 5 Flexible stranded copper
Insulation: Rubber Compound type EV1-2
Control Cores: Class 5 Flexible Copper Conductor
Tape: Longditudinal Water Blocking Tape
Pilot Core Insulation: Rubber
Sheath: Thermoplastic Polyurethane (TPEM)

CHARACTERISTICS

Voltage Rating: 450/750 Volts
Temperature Limits: -35°C to +90°C
Maximum Short Circuit Temp: +250°C
Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed at temperatures below 0°C

PRODUCTS

CodeDescription
CONNECTEVH07BZ53X1/53X1.5 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ53X2/53X2.5 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ53X43X4 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ53X63X6 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ53X103X10 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ53X163X16 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ53X253X25 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ53X353X35 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ54X2/54X2.5 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ54X44X4 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ54X64X6 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ54X104X10 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ54X164X16 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ54X254X25 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ54X354X35 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ55X2/55X2.5 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ55X45X4 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ55X65X6 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ55X105X10 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ55X165X16 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ55X255X25 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
CONNECTEVH07BZ55X355X35 H07BZ5-F EV CHARGING CABLE FLEX RUBBER TPEM
