CONNECTEV LSZH ELECTRIC VEHICLE CHARGING & 4 PAIR FTP CAT5E CABLE
OVERVIEW
This cable is for use in the installation of electric vehicle charge points. This is a combined armoured 3 core power and 4 pair CAT5e Data cable in a double sheathed design for extra protection.
Whilst designed for use in electric vehicle chargepoints, the cable is suitable for other installations where power and CAT5e Data cable is required.
Whilst designed for use in electric vehicle chargepoints, the cable is suitable for other installations where power and CAT5e Data cable is required.
STANDARDS
- IEC 60228
- IEC 60502-1
- IEC 60332-1-2
- IEC 60754-1
- IEC 61034-2
- IEC 60332-3-24 CAT C
CONSTRUCTION
Conductor: Class 5 Flexible Stranded Copper
Insulation: XLPE (Cross Link Polyethelene)
Bedding: LSZH (Low Smoke Zero Halogen)
Sheath: LSZH (Low Smoke Zero Halogen)
Sheath Colour: Black
CHARACTERISTICS
Voltage Rating: 600 - 1000 Volts
Test Voltage: 4kV
Temperature Limits: -30°C to +80°C
Minimum Bending Radius: As per cable manufacturer datasheet
