OVERVIEW

Pre-cut & bespoke H07RN-F EPR cable with a large variety of connectors. Flexible, with a high resistance to mechanical stress. For the events/generator industries & film/theatre applications. Available in both single and 3 phase 230V-415V. 3 and 5 core from 2.5mm up to 50mm and single core from 50mm up to 240mm. Cut in standard lengths of 5, 10, 15, 20 and 25 metres or bespoke to customers individual requirements. We can also produce as lug to lug or powerlock to lug.
STANDARDS
  • BS EN 50525-2-21
  • BS EN 60811-2-1
  • BS EN/IEC 60332-1-2
CONSTRUCTION

Conductor: Class 5 flexible stranded copper conductor to BS EN 60228
Insulation: EPR (Ethylene Propylene Rubber) to BS 50363
Sheath: PCP (Polychloroprene) to BS EN 50363

CHARACTERISTICS

Voltage Rating: 230-415V
Temperature Limits: -25°C to +60°C, Can be supplied up to 90°C
Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed below 0°C

PRODUCTS


CodeDescription
3183P2/5EXT/16230V 16AMP 1 PHASE IP44(HO7 2.5MM) EXTENSION LEAD C/W PLUG & SOCKET
3185P2/5EXT/16415V 16AMP 3 PHASE IP44(HO7 2.5MM) EXTENSION LEAD C/W PLUG & SOCKET
3183P4EXT/32230V 32AMP 1 PHASE IP44(HO7 4MM) EXTENSION LEAD C/W PLUG & SOCKET
3185P4EXT/32415V 32AMP 3 PHASE IP44(HO7 4MM) EXTENSION LEAD C/W PLUG & SOCKET
6385P10EXT/63415V 63AMP 3 PHASE IP67(H07 10MM) EXTENSION LEAD C/W PLUG & SOCKET
6385P16EXT/63415V 63AMP 3 PHASE IP67(H07 16MM) EXTENSION LEAD C/W PLUG & SOCKET
6385P25EXT/125415V 125AMP 3 PHASE IP67(H07 25MM) EXTENSION LEAD C/W PLUG & SOCKET
6385P35EXT/125415V 125AMP 3 PHASE IP67(H07 35MM) EXTENSION LEAD C/W PLUG & SOCKET
6385P50EXT/125415V 125AMP 3 PHASE IP67(H07 50MM) EXTENSION LEAD C/W PLUG & SOCKET
6381P50EXT/1400A LINE SOURCE 1 TO LINE DRAIN 1(H07 50MM) EXTENSION LEAD
6381P50EXT/2400A LINE SOURCE 2 TO LINE DRAIN 2(H07 50MM) EXTENSION LEAD
6381P50EXT/3400A LINE SOURCE 3 TO LINE DRAIN 3(H07 50MM) EXTENSION LEAD
6381P50EXT/N400A LINE SOURCE N TO LINE DRAIN N(H07 50MM) EXTENSION LEAD
6381P50EXT/E400A LINE SOURCE E TO LINE DRAIN E(H07 50MM) EXTENSION LEAD
6381P70EXT/1400A LINE SOURCE 1 TO LINE DRAIN 1(H07 70MM) EXTENSION LEAD
6381P70EXT/2400A LINE SOURCE 2 TO LINE DRAIN 2(H07 70MM) EXTENSION LEAD
6381P70EXT/3400A LINE SOURCE 3 TO LINE DRAIN 3(H07 70MM) EXTENSION LEAD
6381P70EXT/N400A LINE SOURCE N TO LINE DRAIN N(H07 70MM) EXTENSION LEAD
6381P70EXT/E400A LINE SOURCE E TO LINE DRAIN E(H07 70MM) EXTENSION LEAD
6381P95EXT/1400A LINE SOURCE 1 TO LINE DRAIN 1(H07 95MM) EXTENSION LEAD
6381P95EXT/2400A LINE SOURCE 2 TO LINE DRAIN 2(H07 95MM) EXTENSION LEAD
6381P95EXT/3400A LINE SOURCE 3 TO LINE DRAIN 3(H07 95MM) EXTENSION LEAD
6381P95EXT/N400A LINE SOURCE N TO LINE DRAIN N(H07 95MM) EXTENSION LEAD
6381P95EXT/E400A LINE SOURCE E TO LINE DRAIN E(H07 95MM) EXTENSION LEAD
6381P120EXT/1400A LINE SOURCE 1 TO LINE DRAIN 1(H07 120MM) EXTENSION LEAD
6381P120EXT/2400A LINE SOURCE 2 TO LINE DRAIN 2(H07 120MM) EXTENSION LEAD
6381P120EXT/3400A LINE SOURCE 3 TO LINE DRAIN 3(H07 120MM) EXTENSION LEAD
6381P120EXT/N400A LINE SOURCE N TO LINE DRAIN N(H07 120MM) EXTENSION LEAD
6381P120EXT/E400A LINE SOURCE E TO LINE DRAIN E(H07 120MM) EXTENSION LEAD
6381P150EXT/1400A LINE SOURCE 1 TO LINE DRAIN 1(H07 150MM) EXTENSION LEAD
6381P150EXT/2400A LINE SOURCE 2 TO LINE DRAIN 2(H07 150MM) EXTENSION LEAD
6381P150EXT/3400A LINE SOURCE 3 TO LINE DRAIN 3(H07 150MM) EXTENSION LEAD
6381P150EXT/N400A LINE SOURCE N TO LINE DRAIN N(H07 150MM) EXTENSION LEAD
6381P150EXT/E400A LINE SOURCE E TO LINE DRAIN E(H07 150MM) EXTENSION LEAD
6381P240EXT/1660A LINE SOURCE 1 TO LINE DRAIN 1(H07 240MM) EXTENSION LEAD
6381P240EXT/2660A LINE SOURCE 2 TO LINE DRAIN 2(H07 240MM) EXTENSION LEAD
6381P240EXT/3660A LINE SOURCE 3 TO LINE DRAIN 3(H07 240MM) EXTENSION LEAD
6381P240EXT/N660A LINE SOURCE N TO LINE DRAIN N(H07 240MM) EXTENSION LEAD
6381P240EXT/E660A LINE SOURCE E TO LINE DRAIN E(H07 240MM) EXTENSION LEAD
