SY Control Flex Temporary Power Leads - 2.5mm to 4mm
SY Control Flex Temporary Power Leads - 2.5mm to 4mm


OVERVIEW

Pre-cut & bespoke PVC SY Control cable with a large range of connectors. Flexible, with a high resistance to mechanical stress. For the events/generator industries & film/theatre applications. Available in both single and 3 phase 230V-415V. 3 and 5 core from 2.5mm up to 50mm and single core from 50mm up to 240mm. Cut in standard lengths of 5, 10, 15, 20 and 25 metres or bespoke to customers individual requirements. We can also produce as lug to lug or powerlock to lug.

STANDARDS
  • Generally to BS EN 50525-2-11
  • VDE 0250
CONSTRUCTION

Conductor: Plain Annealed Stranded Copper Conductors
Insulation: PVC
Bedding: PVC
Armouring: Galvanised Steel Wire Braid
Armour Sheath: Transparent PVC
Sheath Colour: N/A

CHARACTERISTICS

Voltage Rating: 230-415V
Temperature Limits: -25°C to +60°C, Can be supplied up to 90°C
Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed below 0°C

PRODUCTS


CodeDescription
SY3X2/5EXT/16230V 16AMP 1 PHASE IP44(SY 2.5MM) EXTENSION LEAD C/W PLUG & SOCKET
SY3X4EXT/32230V 32AMP 1 PHASE IP44(SY 4.0MM) EXTENSION LEAD C/W PLUG & SOCKET
SY5X2/5EXT/16415V 16AMP 3 PHASE IP44(SY 2.5MM) EXTENSION LEAD C/W PLUG & SOCKET
SY5X4EXT/32415V 32AMP 3 PHASE IP44(SY 4MM) EXTENSION LEAD C/W PLUG & SOCKET
SY3X2/5EXT/16230V 16AMP 1 PHASE IP44(SY 2.5MM) EXTENSION LEAD C/W PLUG & SOCKET
SY3X4EXT/32230V 32AMP 1 PHASE IP44(SY 4.0MM) EXTENSION LEAD C/W PLUG & SOCKET
SY5X2/5EXT/16415V 16AMP 3 PHASE IP44(SY 2.5MM) EXTENSION LEAD C/W PLUG & SOCKET
SY5X4EXT/32415V 32AMP 3 PHASE IP44(SY 4MM) EXTENSION LEAD C/W PLUG & SOCKET
