ENATS 09-6 Telecommunications Cable - PE, SWA, PVC - 0.50mm
ENATS 09-6 Telecommunications Cable - PE, SWA, PVC - 0.50mm


OVERVIEW

ENATS 09-6 Telecommunication cable is a polythene insulated, multipair, light current control cable which is intended to be used for feeder protection in control, alarm equipment and switchgear. The cable can also be used in power stations where the voltage does not exceed 150V d.c or 110V a.c. The cable can be installed where there is risk of mechanical impact due to the steel wired armouring.
Standards
  • ENATS 09-6 issue 8 table E2A/E2.B section 2 - induced voltage between the pairs up to 15kV
Construction

Conductor: Solid plain annealed copper conductors
Insulation: Polyethylene insulated
Bedding: Polyethylene bedding
Armouring: Galvanised steel wire armour
Sheath: PVC sheath
Sheath Colour: Black

Characteristics

Temperature limits: -20°C to +70°C
Minimum Bending Radius: As Per Manufacturers Datasheet

Should not be installed at temperatures below 0°C or above +40°C

PRODUCTS


CodeDescription
131877X2X1/0.8 POLY,POLY,SWA,PVC,ENATS 09-6 ISSUE 8 TABLE E2A/E2B SECTION 2 BLACK,15KV
1318819X2X1/0.8 POLY,POLY,SWA,PVC,ENATS 09-6 ISSUE 8 TABLE E2A/E2B SECTION 2 BLACK,15KV
