ENATS 09-6 Telecommunications Cable - SCR, SWA - 0.50mm
OVERVIEW
Telecommunication cable is predominantly used in electrical instrumentation and communications. The cable is manufactured to specification ENATS 09-6 Section 4.5. (Electrical National Association and Technical specification). ENATS is the governing body who cover utilities specification cables.
Standards
- ENATS 09-6 Issue 8 Section 4.5
- Flame propagation to BS4066 PT1 and IEC 332 PT1
Construction
Conductor: Solid Plain Annealed Copper Conductors
Screen: Collective Aluminium / Mylar tape screen with 0.5mm2 drain wire
Insulation: Polyvinyl Chloride (PVC)
Bedding: Polyvinyl Chloride (PVC)
Armouring: Galvanised Steel Wire Armour
Sheath: Polyvinyl Chloride (PVC)
Sheath Colour: Black
Characteristics
Temperature limits: -20°C to +70°C
Minimum Bending Radius: As Per Manufacturers Datasheet
Should not be installed at temperatures below 0°C or above +40°C
