BS6346/87 Armoured Loop Feeder Cable - 1.5mm to 2.5mm
OVERVIEW
Armoured Polyethylene Loop Feeder Cable is primarily used to connect traffic signals to the main management console in permanent traffic light systems and urban traffic management systems. Armoured Loop Feeder Cable is available from stock for use in ducts or for direct burial.
STANDARDS
- BS 6346/87
CONSTRUCTION
Conductor: Plain Annealed Solid Copper
Insulation: Polyethylene (PE)
Bedding: Polyethylene (PE)
Armouring: Galvanised Steel Wire Armour
Sheath: Polyethylene (PE)
Sheath Colour: Orange
CHARACTERISTICS
Voltage Rating: 600/1000 Volts
Temperature Limits: -15°C to +70°C
Minimum Bending Radius: As per cable manufacturer datasheet
Should not be installed at temperatures below 0°C or above +60°C
