BS6346/87 Armoured Traffic Signal Cable - 1mm to 1.5mm
BS6346/87 Armoured Traffic Signal Cable - 1mm to 1.5mm



OVERVIEW

Armoured PVC traffic signal cable, used to connect traffic signal equipment or in other applications that require high core configurations with tough mechanical robustness.
STANDARDS
  • BS6346/87
CONSTRUCTION

Conductor: Annealed Solid Copper Conductor
Insulation: Polyvinyl Chloride (PVC)
Bedding: Polyvinyl Chloride (PVC)
Armour: Galvanised Steel Wire (SWA)
Sheath: Polyvinyl Chloride (PVC)
Sheath Colour: Orange

CHARACTERISTICS

Voltage Rating: 600/1000V
Temperature Limits: -15°C to +70°C
Minimum Bending Radius: As per cable manufacturer datasheet

For more information please consult a member of the Cleveland Cable Sales Team

PRODUCTS


CodeDescription
TRAF4X14X1(1) PVC,PVC,SWA,PVC TRAF OPTION 1 C/CORE 1KV BS6346, ORANGE,BULK
TRAF8X18X1(1) PVC,PVC,SWA,PVC TRAF OPTION 1 C/CORE 1KV BS6346, ORANGE, BULK
TRAF12X112X1(1)PVC,PVC,SWA,PVC TRAF OPTION 1 C/CORE 1KV BS6346, ORANGE, R250, MAX DRUM WIDTH FOR 250M DRUMS 480mm
TRAF16X116X1(1)PVC,PVC,SWA,PVC TRAF OPTION 1 C/CORE 1KV BS6346, ORANGE, R250, MAX DRUM WIDTH FOR 250M DRUMS 480mm
TRAF20X120X1(1)PVC,PVC,SWA,PVC TRAF OPTION 1 C/CORE 1KV BS6346, ORANGE, R250, MAX DRUM WIDTH FOR 250M DRUMS 480mm
TRAF4X1/54X1.5(1)PVC,PVC,SWA,PVC TRAF OPTION 1 C/CORE 1KV BS6346, ORANGE, BULK
TRAF8X1/58X1.5(1)PVC,PVC,SWA,PVC TRAF OPTION 1 C/CORE 1KV BS6346, ORANGE, BULK
TRAF12X1/512X1.5(1)PVC,PVC,SWA,PVC TRAF OPTION 1 C/CORE 1KV BS6346, ORANGE, R250 ,MAX DRUM WIDTH FOR 250M DRUMS 480mm
TRAF16X1/516X1.5(1)PVC,PVC,SWA,PVC TRAF OPTION 1 C/CORE 1KV BS6346, ORANGE, R250, MAX DRUM WIDTH FOR 250M DRUMS 480mm
TRAF20X1/520X1.5(1)PVC,PVC,SWA,PVC TRAF OPTION 1 C/CORE 1KV BS6346, ORANGE, R250, MAX DRUM WIDTH FOR 250M DRUMS 480mm
TRAF8X1ESWA8X1(1)+6MM EARTH PVC,SWA,PVC TRAFFIC OPTION 1 C/CORES 1KV BS6346, ORANGE, BULK
