309*Y FLEXIBLE CABLE - H05V2V2-F, PVC - 0.5MM TO 2.5MM
OVERVIEW
309*Y Flexible PVC Cable used in the installation of external electrical appliances. Generally used with appliances that reach / maintain hot temperatures such as heaters. Temperature limits of the 309*Y PVC cable range from -5 to +90°C.
STANDARDS
- BS EN 50525-2-11
CONSTRUCTION
Conductor: Plain annealed flexible stranded copper conductor
Insulation: Heat Resisting Polyvinyl Chloride (PVC)
Sheath: Polyvinyl Chloride (PVC)
CHARACTERISTICS
Voltage Rating: 300/500V
Temperature Rating:
Fixed: -5°C to +90°C
Flexing: +5°C to +90°C
Minimum Bending Radius: As per cable manufacturer datasheet
Should not be installed at temperatures below 0°C
For more information please consult a member of the Cleveland Cable Sales Team
