FGT Cable - Class 2 - Non-Armoured, Copper, XLPE, PVC - 10mm to 120mm
FGT Cable - Class 2 - Non-Armoured, Copper, XLPE, PVC - 10mm to 120mm


OVERVIEW

Power distribution cable for signal operations. With Water Blocking Tape to prevent water ingress and built in fibre glass tape to make it rodent-proof.
Standards
  • Conductor to BS EN 60228 (previously BS 6360)
  • XLPE Insulation to to BS7655-1-3
  • BS EN 60811-1
  • IEC 60502-1
  • Network Rail Specification NR/L2/SIGELP/27408
Construction

Conductor:
Up to 25mm2: Class 1 solid, copper circular or sector shaped conductor
35mm2 and above: Class 2 Stranded copper sector shaped
Insulation: Cross-Linked Polyethylene (XLPE)
Anti Rodent Protection: Fibre glass woven tape (FGT)
Water Blocking: Water blocking tape placed under and over the FGT anti rodent protection
Moisture Barrier: Aluminium/polymerlaminate tape
Sheath: Black Poly Vinyl Chloride (PVC)

Characteristics

Voltage Rating: 600/1000 Volts
Temperature limits: -15°C to +90°C

PRODUCTS


CodeDescription
FGT2X10WBCU2X10MM CU XLPE WB FGT WB PVC 0.6/1KV 006/186019
FGT2X16WBCU2X16MM CU XLPE WB FGT WB PVC 0.6/1KV 006/186020
FGT2X25WBCU2X25MM CU XLPE WB FGT WB PVC 0.6/1KV 006/186021
FGT2X35WBCU2X35MM CU XLPE WB FGT WB PVC 0.6/1KV 006/186022
FGT2X50WBCU2X50MM CU XLPE WB FGT WB PVC 0.6/1KV 006/186023
FGT2X70WBCU2X70MM CU XLPE WB FGT WB PVC 0.6/1KV 006/186024
FGT2X95WBCU2X95MM CU XLPE WB FGT WB PVC 0.6/1KV 006/186025
FGT2X120WBCU2X120MM CU XLPE WB FGT WB PVC 0.6/1KV 006/186026
FGT4X10WBCU4X10MM CU,XLPE,WBT,FGT,WBT,PVC 0.6/1KV 006
FGT4X16WBCU4X16MM CU,XLPE,WBT,FGT,WBT,PVC 0.6/1KV 006
FGT4X25WBCU4X25MM CU,XLPE,WBT,FGT,WBT,PVC 0.6/1KV 006
FGT4X35WBCU4X35MM CU,XLPE,WBT,FGT,WBT,PVC 0.6/1KV 006
FGT4X50WBCU4X50MM CU,XLPE,WBT,FGT,WBT,PVC 0.6/1KV 006
FGT4X70WBCU4X70MM CU,XLPE,WBT,FGT,WBT,PVC 0.6/1KV 006
FGT4X95WBCU4X95MM CU,XLPE,WBT,FGT,WBT,PVC 0.6/1KV 006/147010
FGT3X10WBCU3X10MM CU XLPE WB FGT WB PVC 0.6/1KV
FGT3X16WBCU3X16MM CU XLPE WB FGT WB PVC 0.6/1KV
FGT3X25WBCU3X25MM CU XLPE WB FGT WB PVC 0.6/1KV
FGT3X35WBCU3X35MM CU XLPE WB FGT WB PVC 0.6/1KV
FGT3X50WBCU3X50MM CU XLPE WB FGT WB PVC 0.6/1KV
FGT3X70WBCU3X70MM CU XLPE WB FGT WB PVC 0.6/1KV
FGT3X95WBCU3X95MM CU XLPE WB FGT WB PVC 0.6/1KV
FGT3X120WBCU3X120MM CU XLPE WB FGT WB PVC 0.6/1KV
