ENATS 09-6 Telecommunications Cable - SCR, SWA, LSZH - 0.50mm
OVERVIEW
Telecommunication cable, available in 0.5mm and 2, 5, 10 or 20 pairs and manufactured to ENATS 09-6. The cable features solid plain annealed copper conductors, polyethylene insulated, twisted to form pairs, collective aluminium/mylar foil tape screen complete with 0.5mm2 drain, wire, low smoke zero halogen (LSZH) bedding, galvanised steel wire armour, low smoke and zero halogen (LSZH) sheath. Black. Generally to ENATS 09-6: Issue 6 Section 4.5.
The primary use of this telecommunication cable is with control indication and alarm equipment for switchgear. They are suitable for installing in circuits where the minimal voltage does not exceed ISOV DC or 11OVaC.
The primary use of this telecommunication cable is with control indication and alarm equipment for switchgear. They are suitable for installing in circuits where the minimal voltage does not exceed ISOV DC or 11OVaC.
Standards
- ENATS 09-6: Issue 8 Section 4.5
- Flame propagation to:
IEC BS4066 PT1
IEC 332 PT1
Construction
Conductor: Solid Plain Annealed Copper Conductors
Insulation: Low Smoke Zero Halogen (LSZH)
Screen: Collective Aluminium / Mylar tape screen with 0.5mm2 drain wire
Bedding: Low Smoke Zero Halogen (LSZH)
Armouring: Galvanised Steel Wire Armour
Sheath: Low Smoke Zero Halogen (LSZH)
Sheath Colour: Black
Characteristics
Temperature limits: -30°C to +70°C
Minimum Bending Radius: As Per Manufacturers Datasheet
Should not be installed at temperatures below 0°C or above +40°C
