6941AB Power Cable - BS6724, XLPE, AWA, LSZH - 50mm to 1000mm
6941AB Power Cable - BS6724, XLPE, AWA, LSZH - 50mm to 1000mm


OVERVIEW

Designed for use in AC circuits, the aluminium armour prevents magnetic build up. Suitable for power networks and direct burial where fire and emissions of smoke and toxic fumes create a serious potential threat.
Standards
  • BS 6724
  • Flame propagation to IEC 60332-1, IEC 60332-3
  • BS EN 50265, Category C; BS EN 50266
  • Smoke emission to BS EN 50268 (IEC 61034)
  • Acid gas emission to BS EN 50267 (IEC 60754-1)
  • BASEC approved
CONSTRUCTION

Conductor: Stranded Plain Annealed Compacted Circular Copper Conductors
Insulation: Cross Link Polyethylene (XLPE)
Bedding: LSZH Extruded Bedding
Armouring: Aluminium Wire Armour
Sheath: LSZH

CHARACTERISTICS

Voltage Rating: 600/1000 Volts
Temperature limits: -25°C to +90°C
Minimum Bending Radius: As Per Manufacturers Datasheet

Should not be installed at temperatures below 0°C or above +40°C

PRODUCTS

CodeDescription
6941AB501X50 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724
6941AB701X70 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724
6941AB951X95 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724
6941AB1201X120 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724 BASEC
6941AB1501X150 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724 BASEC
6941AB1851X185 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724 BASEC
6941AB2401X240 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724 BASEC
6941AB3001X300 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724 BASEC
6941AB4001X400 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724
6941AB5001X500 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724
6941AB6301X630 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724
6941AB8001X800 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724 BASEC
6941AB10001X1000 CU,XLPE,BROWN,LSZH,AWA,LSZH,BLACK,1KV BS6724 BASEC
