H07VVH6-F PVC Flatform Cable - CENELEC HD 359 S2, IEC 227 part 6 - 1.5mm to 95mm
OVERVIEW
Overview
PVC Flatform Cable is designed for power and control systems, cranes and control bridges, moving machinery such as overhead cranes and hoisting systems. The cable is suitable for use indoors and outdoors in dry, humid and wet conditions. To Harmonised code H07VVH6-F
PVC Flatform Cable is designed for power and control systems, cranes and control bridges, moving machinery such as overhead cranes and hoisting systems. The cable is suitable for use indoors and outdoors in dry, humid and wet conditions. To Harmonised code H07VVH6-F
Standards
- CENELEC HD 359 S2
- IEC 227 part 6
- H07VVH6-F
Construction
Conductor: Flexible Plain Copper Conductors
Insulation: Polyvinyl Chloride (PVC)
Sheath: Special Polyvinyl Chloride (PVC)
Sheath Colour: Black
Characteristics
Voltage Rating: 450/750 volts
Temperature limits: -25°C to +70°C
Minimum Bending Radius: As Per Manufacturers Datasheet
Should not be installed at temperatures below 0°C
