NEK606 BFOU Power & Instrumentation Cable - Mud Resistant - 0.75mm to 35mm
NEK606 BFOU Power & Instrumentation Cable - Mud Resistant - 0.75mm to 35mm


OVERVIEW

BFOU fire resistant and flame retardant, halogen free power and instrumentation marine cables for fixed installation in electromechanical and electric equipment, emergency and critical systems, lighting and electric distribution systems. Suitable for use in all conditions in a marine environment such as muddy, dry, wet and oily conditions meeting the requirements of NEK 606.
STANDARDS
  • IEC 60228 class 2
  • IEC 60092-353
  • IEC60754-1, 2
  • IEC60332-3/A
  • IEC61034-1,2
  • Mud Resistant to NEK606
CONSTRUCTION

Conductor: Copper Conductor
Insulation: Ethylene Propylene (EPR)
Bedding: Halogen Free Mud Resistant Bedding
Armouring: Tinned copper wire braid
Sheath: Mud resistant sheath
Sheath Colour:
Power Cables: Black
Instrumentation Cables: Grey or Blue

CHARACTERISTICS

Voltage Rating: 600/1000 volts *Instrumentation Cable 150-250 Volts
Temperature Limits: -40°C (fixed installation) to +90°C
Minimum Bending Radius: As per cable manufacturer datasheet

PRODUCTS


CodeDescription
BFOU2X1/52X1.5 STCC CLASS 2, MGT, EPR, HFC TCWB, SHF2 BLACK SHEATH, BLUE & BROWN CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU3X1/53X1.5 STCC CLASS 2, MGT, EPR, HFC, TCWB, SHF2, BLACK SHEATH, BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU4X1/54X1.5 STCC CLASS 2, MGT, EPR, HFC, TCWB, SHF2, BLACK SHEATH, BLUE BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU5X1/55X1.5 STCC CLASS 2, MGT, EPR, HFC, TCWB, SHF2, BLACK SHEATH, BLUE BROWN BLACK GREY & BLACK CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU7X1/57X1.5 STCC CLASS 2, MGT, EPR, HFC, TCWB,SHF2, BLACK SHEATH, WHITE WITH BLACK NUMBERED CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU12X1/512X1.5 STCC CLASS 2, MGT, EPR, HFC, TCWB, SHF2, BLACK SHEATH, WHITE WITH BLACK NUMBERED CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU2X2/52X2.5 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BLUE & BROWN CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU3X2/53X2.5 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU4X2/54X2.5 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BLUE BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU5X2/55X2.5 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BLUE BROWN BLACK GREY & BLACK CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU7X2/57X2.5 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, WHITE WITH BLACK NUMBERED CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU12X2/512X2.5 STCC CLASS 2, MGT, EPR, HFC, TCWB, SHF2, BLACK SHEATH, WHITE WITH BLACK NUMBERED CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU2X42X4 STCC CLASS 2, MGT, EPR, EPR, TCWB, EVA, BLACK SHEATH, BLUE & BROWN CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU3X43X4 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU4X44X4 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BLUE BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU2X62X6 STCC CLASS 2, MGT, EPR, EPR, TCWB, EVA, BLACK SHEATH, BLUE & BROWN CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU3X63X6 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU4X64X6 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BLUE BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU2X102X10 STCC CLASS 2, MGT, EPR, EPR, TCWB, EVA, BLACK SHEATH, BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU3X103X10 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU4X104X10 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH,BLUE BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU2X162X16 STCC CLASS 2, MGT, EPR, EPR, TCWB, EVA, BLACK SHEATH, BLUE & BROWN CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU3X163X16 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU4X164X16 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, TCWB, EVA, BLACK SHEATH, BLUE BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU4X254X25 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BLUE BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU4X354X35 STCC CLASS 2,MGT,EPR,HFC,TCWB,SHF2, BLACK SHEATH, BLUE BROWN BLACK & GREY CORES, 0.6/1(1.2)KV NEK 606 CODE P5/P12 IEC 60331-21, MUD RESISTANT
BFOU1X2X/75GY*1X2X0.75 STCC, MICA,EPR,EPR,LSZH,O/SCR,CU/PETP,EVA,GY SHEATH, 250V NEK 606 S4/S8, IEC60331-21,LIGHT BLUE & BLACK NUMBERED PAIRS, MUD RESISTANT
BFOU2X2X/75GY*2X2X0.75 STCC,MICA,EPR,EPR,LSZH,O/SCR,CU/PETP,EVA,GY SHEATH,250V NEK 606 S4/S8,IEC60331-21, LIGHT BLUE & BLACK NUMBERED PAIRS, MUD RESISTANT
BFOU1X3X/75*1X3X0.75 STCC,MICA,EPR,EPR,LSZH,O/SCR,CU/PETP,EVA,GREY SHEATH,250V NEK 606 S4/S8,IEC60331-21,BLACK LIGHT BLUE & BROWN NUMBERED TRIPLES, MUD RESISTANT
BFOU1X2X1/5GY*1X2X1.5 STCC,MICA,EPR,EPR,LSZH,O/SCR,CU/PETP,EVA,GREY SHEATH,250V NEK 606 S4/S8, IEC60331-21, LIGHT BLUE AND BLACK NUMBERED PAIRS, MUD RESISTANT
BFOU2X2X1/5GY*2X2X1.5 STCC,MICA,EPR,EPR,lSZH,O/SCR,CU/PETP,EVA,GREY SHEATH,250V NEK 606 S4/S8, IEC60331-21, LIGHT BLUE AND BLACK NUMBERED PAIRS, MUD RESISTANT
BFOU1X3X1/5GY*1X3X1.5 STCC,MICA,EPR,EPR,LSZH,O/SCR,CU/PETP,EVA,GREY SHEATH,250V NEK 606 S4/S8, IEC60331-21, BLACK LIGHT BLUE & BROWN NUMBERED TRIPLES, MUD RESISTANT
